A&I Products Red LED Tail Light - A-WL7882

This lamp requires the black ground wire eyelet to be grounded properly for light to function. It may be connected to the existing light mounting screws with an internal tooth lock washer & nut or to the fender panel with a self-tapping screw. (hardware not included with light)

Red polycarbonate lens

3 - 3 Watt LED Epistar Diodes

Black wire ground, red wire high beam, white wire low beam

Can wire for Hi / Low (Brake Light) function

    Diode: (3) 3 Watt LED Epistar Diodes

    Mount: 4 mounting holes 4" apart side to side & 3" apart top to bottom

    Replaces: AR78825, Grote 455, 30-3153347, 72160473

    Volt/Amperage: For 10 - 30 Volt systems

This is an aftermarket part. Not OEM.
